Teräsruuvi teräkseen PH2 clear zinc 4,8x19mm

Klikkaa suurentaaksesi kuvaa

Kuvaus

Tiuha ruuvi teräkseen, sähkösinkitty

Lue lisää Lue vähemmän

Normin versio EN 14566:2008+A1:2009

Eritelmät

Identifiointi

Nimike: 48IP19MC
GTIN: 8715274028149

Tekniset tiedot

Sidostyyppi: Muovisidottu
Lankamateriaalli: hiiliteräs, vakiokarkaisu
Kierrosnopeus: 2300, 2500, 3000, 3300 RPM

Kiinnnittimen tiedot

Viimeistely: Clear zinc
Käyttökohde: Kuivat sisätilat
Kärjen tyyppi: Tyypin 17 leikkava kärki
teroituskulma: 110 °
Ruuvin kantaprofiili: Tasarulla
Ruuvikannan tyyppi: Philips 2
Ruuvin kierteen tyyppi: Itseporautuva (Tek)
Kamman/rullan kiinnikkeiden määrä: 50 - 50
Ruuvin pituus: 19.0 mm
Ruuvin halkaisija: 4.8 mm

CE merkinnät

DOP No: 48IP19MC
Käyttöluokka: 1
Kierteen sisähalkaisija: 3.8 mm
Kierteisen osan pituus: 13.9 mm
Normin versio: EN 14566:2008+A1:2009

Muut kuin tekniset tiedot

Pakkauksen määrä: 1000

Logistiset tiedot

Nettopaino: 2.4 kg

Vastaavat työkalut

Lataukset

48IP19MC_fi_CommercialProductSheet_1.5_1752233795242 PDF 1 Mb
48IP19MC_fi_DeclarationOfPerformanceDoP_1.1eu_1750109897939 PDF 58 Kb
